Standard apparatus for determining aggregate
impact value of coarse aggregates.
Aggregate Impact Testing Machine is designed for determining the aggregate impact value of coarse aggregates. Manufactured with precision components for accurate and reliable testing in civil engineering and material testing laboratories.
Request Quote Specifications
Accurate determination of aggregate impact value as per standard test methods.
The Aggregate Impact Testing Machine works on the principle of subjecting a prepared aggregate sample to a controlled impact load and measuring the resistance offered by the aggregate to fracture.
A standard quantity of aggregate is placed in a cylindrical cup and compacted. A standard hammer is then allowed to fall freely through a fixed height, giving a specified number of blows to the sample.
The crushed aggregate is sieved and the percentage passing the specified sieve is calculated as the aggregate impact value, which indicates the resistance of the aggregate to sudden impact or shock.
| Product Name | Aggregate Impact Testing Machine |
| Application | Aggregate Impact Value of Coarse Aggregates |
| Machine Body | Sturdy Steel Construction |
| Cup Dimensions | 102 mm Diameter × 50 mm Depth (Approx.) |
| Hammer Weight | 13.5 kg (Approx.) |
| Hammer Fall Height | 380 mm (Approx.) |
| Blows Per Test | 15 Blows |
| Accessories | Standard Cup, Hammer, Tamping Rod & Base |
| Standard Compliance | As Per Standard Test Methods |
| Customization | Custom Specifications Available on Request |
Aggregate Impact Testing Machine provides accurate and repeatable results for determining the impact value of coarse aggregates. It is built with precision components for reliable performance in material testing laboratories.
It is used to determine the aggregate impact value of coarse aggregates, which indicates their resistance to sudden impact or shock.
The standard hammer weight is approximately 13.5 kg and is dropped from a fall height of about 380 mm.
The standard test specifies 15 blows to the aggregate sample in the cup.
Standard accessories include the cylindrical cup, hammer, tamping rod and base plate.
The machine is primarily designed for coarse aggregates, as per standard test specifications.
Yes, custom specifications can be provided on request.
For specifications and quotation, contact Labtek Enterprises.
